| Shell | Aluminum Alloy |
| Shell Plating | Electroless Nickel, Yellow Chromate/Cadmium over nickel, Gold over Nickel, Irridite/Alodine or Black anodize |
| Insulator | Liquid Crystal Polymer (LCP) per MIL-M-24519, Type GLCP-30F (9-100), Glass filled diallyl phthalate per MIL-M-14, Type SDGF (7*2 and 24*4), Polyphenylene sulfide per MIL-M-24519, Type GST-40F (16*5), Polyester per MIL-M-24519, Type GPT-30F (10*10) |
| Contact | Copper alloy |
| Contact Plating | Gold |
| Shape | D Shape |
| Shell Style | Straight Flange mount Plug, Straight Flange mount Receptacle |
| Durability | 500 Mating Cycles |
| Power & Signal In Same Layout | Yes |
| Contact Style / Termination | Factory terminated wire, Solder pots |
| Sealing | N/A |
| Operation Temperature | -55°C to +125°C (+200°C) |
| Operating Voltage | 400 VAC |
| Current Rating | 3A |
| Number of Signal Contacts (Min/Max) | 9, 15, 21, 25, 31, 37, 51, 100 |
| Gauge Wire Size | AWG 24 thru AWG 32 |
